King Permanent Lighting 36V Outdoor Power Supply — 400W
Regular price
$142.99
Couldn't load pickup availability
Got questions?
Feel free to get in touch
Built for installers. Used on real jobs.
This is the gear working contractors run on real rooflines. C9 and C7 LED bulbs, socket wire, clips, plugs, and complete pro light kits at contractor wholesale pricing. Most orders ship same day if placed before 2 PM ET. Free shipping over $349.
The 4-sentence answer
King 36V 400W Outdoor PSU is a 400W outdoor-rated power supply for King Permanent Lighting 36V systems. The system anchor — supplies 36V DC to the controller, which then feeds the LED strings. Compatible with King Permanent Lighting 36V Systems. Use only with the King Permanent Lighting ecosystem — proprietary connectors and controller communication mean cross-brand mixing is not supported.
Why the King 36V 400W Outdoor PSU earns its place on the install
Keep your 36V system powered and performing at full capacity. The King Permanent Lighting 36V Outdoor Power Supply is a robust, weather-ready power solution designed specifically for power injection on extended 36V permanent lighting installations — delivering clean, consistent power where your system needs it most.
- Outdoor Rated – Built to handle exterior environments and all-weather conditions
- High Output Capacity – 400W of clean power delivery for demanding extended runs
- Wide Input Voltage Range – Accepts 90–305VAC for flexible installation across different electrical setups
- Stable Frequency Range – Compatible with 47–63Hz input for broad application compatibility
| Spec | Detail |
|---|---|
| Voltage | 36V |
| Primary Output Voltage | 36V DC |
| Output Current | 8.9 Amps |
| Maximum Output Power | 400W |
| Input Voltage | 90–305VAC |
| Input Frequency | 47–63Hz |
| Application | Power injection for 36V systems |
| Environment | Outdoor / exterior use |
| Compatibility | King Permanent Lighting 36V System |
⚠️ Compatibility Notice: If you are adding this power supply to a 36V system purchased before August 2025, please contact us before ordering to confirm version compatibility.
Verified specifications
Every value below is pulled from the printed bag label / spec sheet. No marketing inflation.
| Voltage output | 36V DC |
|---|---|
| Wattage rating | 400W |
| Voltage input | 120V AC line voltage (GFCI outlet required) |
| Mounting | Inside the King Permanent rated outdoor enclosure box |
| Compatibility | King 36V System |
Where this part fits in the system
Residential 36V permanent installs
400W covers typical residential roofline runs at 36V LED string draw. The system anchor — every 36V install starts with this PSU and the matching 36V controller.
Commercial properties with 36V LED selection
Hotels, multi-tenant buildings, retail with King 36V LED strings selected. The 400W PSU sizes for typical commercial property eave run.
Outdoor enclosure-mounted code-compliant install
Must be installed inside the King Permanent rated outdoor enclosure box for code compliance. GFCI outlet for the 120V supply side.
What this part works with
- Voltage system
- King Permanent Lighting 36V Systems
- Controller
- King Permanent Lighting controller (24V or 36V matching variant)
- Mounting
- Inside the King Permanent rated outdoor enclosure box for code-compliant install. Power supply units must be enclosure-mounted.
- Will NOT work with
- Non-King-Permanent LED strings, controllers, or accessories. The system uses proprietary connectors and controller protocol — cross-brand mixing is not supported.
King 36V 400W Outdoor PSU vs the King 24V 300W PSU baseline
| Spec | King 36V 400W Outdoor PSU | King 24V 300W PSU (baseline) |
|---|---|---|
| Voltage | King Permanent Lighting 36V Systems | 24V DC |
| Function | a 400W outdoor-rated power supply for Ki | Outdoor 24V 300W power supply |
| Best for | The system anchor — supplies 36V DC to the controller, which | Primary 24V system power |
How to install King 36V 400W Outdoor PSU
- Plan the system layout. King Permanent Lighting installs follow a layout-first pattern. Sketch the eave line, PSU location, controller location, and accessory placement before any wire pulls.
- Mount in the rated enclosure. PSU and controller units mount inside the King Permanent outdoor enclosure box for code-compliant install. GFCI outlet required for the supply.
- Route low-voltage wire through protective loom. Use the King Permanent protective loom along the run. Bury or tuck behind soffit where the wire isn't architecturally visible.
- Connect with King proprietary connectors. Don't splice with generic wire nuts. Use the King 3-wire connectors at every junction.
- Commission via the King controller app. Pair the controller via Bluetooth + Wi-Fi. Run a full color cycle to confirm every LED is firing before final mount.
Build quality + materials
- Outdoor-rated construction — designed for year-round outdoor exposure when mounted in the rated King Permanent enclosure box.
- Proprietary connector system — gas-tight connections that survive freeze-thaw and humidity exposure for the life of the install.
- Multi-year permanent install rated — unlike seasonal Christmas lighting, the King Permanent system is designed to stay on the eave year-round.
Warranty
1-year manufacturer warranty on King Permanent Lighting components from Christmas Lights HQ. Not covered: install outside the rated King Permanent enclosure box, cross-brand mixing with non-King components, damage from over-voltage or over-current beyond the rated spec, animal damage.
Questions contractors actually ask
What It's Used For
When your 36V lighting runs exceed the standard port limit, supplemental power injection is required to maintain brightness and performance across the full run. This 400W outdoor power supply is purpose-built for exactly that — reliable, high-output power injection for large-scale 36V installations.
